Ultra 25 / Ultra 45
Sun Fire V125 / V210 / V240
Sun Fire V215 / V245
Sun Fire V440 / V445
Netra 210 / 240 / 440

Options 7703A-4 / 7704A-4 / 7711A-4 / 8703A / 8704A / 8711A

370-7972 370-7973 370-7974
DDR333/PC2700 ECC
512MB Registered DIMM
1GB FRU F540-6466
1GB FRU F540-6776
1GB Option 7703A-4/8703A
DDR333/PC2700 ECC
1GB Registered DIMM
2GB FRU F540-6467
2GB FRU F540-6777
2GB Option 7704A-4/8704A
DDR333/PC2700 ECC
2GB Registered DIMM
4GB FRU F540-6468
4GB Option 7711A-4/8711A

FRU Notes

  1. DIMM 370-7972 was added to 540-6776 in October 2007. (WO_37720)
  2. DIMM 370-7973 was added to 540-6777 in October 2007. (WO_37720)

Ultra 25 and Ultra 45 Notes

  1. Install the first CPU 0 memory pair in either the black slots or the blue slots.
  2. Install the first CPU 1 memory pair in either the black slots or the blue slots.
  3. The minimum requirement is one memory pair in CPU0 black or blue slots.
  4. The minimum memory requirement applies to Single and Dual CPU configurations.

Netra 210 Notes

Factory configured Netra 210 memory changed in October 2006. (WO_34423)
371-1116 became the manufacturing substitute component for 370-7972.
371-1117 became the manufacturing substitute component for 370-7973.

Netra 240 Notes

Factory configured Netra 240 memory changed in August 2006. (WO_33909)
370-7972 was added as a manufacturing substitute component for 371-1116.
370-7973 was added as a manufacturing substitute component for 371-1117.

Netra 440 Notes

Factory configured Netra 440 memory changed in January 2007. (WO_35137)
371-1116 became the manufacturing substitute component for 370-7972.
371-1117 became the manufacturing substitute component for 370-7973.
370-7672 became the manufacturing substitute component for 370-7974.

Sun Fire V125 Notes

  1. Factory configurations with 512MB DIMMs may include 370-7972 or 371-1116.
  2. DIMM 370-7972 is a manufacturing substitute for 370-1116 in V125 assembly 602-3652-01.

Sun Fire V210/V240 Notes

Factory configured Sun Fire V210/V240 memory changed in August 2006. (WO_33861)
370-7972 was added as a manufacturing substitute component for 371-1116.
370-7973 was added as a manufacturing substitute component for 371-1117.

Sun Fire V440 Notes

Factory configured Sun Fire V440 memory changed in January 2007. (WO_34946)
370-7972 was added as a manufacturing substitute component for 371-1116.
370-7973 was added as a manufacturing substitute component for 371-1117.
370-7974 was added as a manufacturing substitute component for 370-7672.

X-Option X7703A-4/X7704A-4/X7711A-4 Notes

Primary and substitute manufacturing parts changed in August 2007. (WO_35640)
370-7972 became the primary and 371-1116 became the substitute.
370-7973 became the primary and 371-1117 became the substitute.
370-7974 became the primary and 370-7672 became the substitute.

References

  1. Sun Ultra 25 Workstation Documentation.
  2. Sun Ultra 45 Workstation Documentation.
  3. Sun Fire V215 Server Documentation.
  4. Sun Fire V245 Server Documentation.
  5. Sun Fire V445 Server Documentation.
  6. Sun Fire V445 Server Supplemental Product Notes, 819-7846.
  7. Netra 210 Server Documentation.
  8. Netra 240 Server Documentation.
  9. Netra 440 Server Documentation.
