Sun Type A239C
1030/2060 Watt Power Supply

<a href="../../Systems/SupportHeaders/DCPOWER_PowerOne_2344_1030W.html">Hmm, you are using a very old browser. Click here to go directly to included content.</a>

300-2344 300-2344 7048278 7048278

Emerson
AC Input Power Supply
Specification 950-5578
UL 60950-1 2nd Edition
EN 60950-1 2nd Edition Power One
AC Input Power Supply
Specification 950-5578
UL 60950-1 2nd Edition
EN 60950-1 2nd Edition Emerson
AC Input Power Supply
Specification 950-5578
UL 60950-1 2nd Edition
EN 60950-1 2nd Edition Power One
AC Input Power Supply
Specification 950-5578
UL 60950-1 2nd Edition
EN 60950-1 2nd Edition

AC Input

100-127Vac

200-240Vac

50-60Hz

12A

DC Output

100-127Vac	+12V 81.3A	+3.3V 10A	1030W
200-240Vac	+12V 165A	+3.3V 10A	2060W

Efficiency of 300-2344

100V	10% Load	>81%
100V	>20% Load	>85%
230V	10% Load	>83%
	20% Load	>90%
	50% Load	>92%
	100% Load	>90%

Power Factor Correction

10% Load	20% Load	50% Load	100% Load
>0.80	>0.90	>0.95	>0.98

Notes

Airflow of the A239C Power Supply is from the power connector to the ejector.
Power Supply Efficiency affects the current draw in AC Watts from the
branch circuit. As efficiency increases, the current draw in AC Watts
decreases.
To calculate maximum theoretical current draw in AC Watts, multiply the
maximum power supply output in DC Watts by the reciprocal of the power
supply efficiency.
Theoretical values are typically higher than published values which are
based on measured outputs under controlled test conditions.
ILOM 3.0.12.2.d, Patch 145667-02, sets the minimum power supply fan speed to
50% to prevent Disk Drive overheating. (BugID 7001959)
The SPARC T3-2 and T4-2 do not support the 100-127Vac input range.
