AC Power Sequencer

Racks: Sun Rack 900, 1000

Option 6849

300-1546

Notes

  1. Each output group of four IEC320 C14 connectors is rated for 10A.
  2. The maximum combined output of all even output groups is 16A.
  3. The maximum combined output of all odd output groups is 16A.
  4. AC Input 0 provides power to switched Groups 0, 2, and 4.
  5. AC Input 1 provides power to switched Groups 5 and 7.
  6. AC Input 1 provides power to unswitched Group 9.
  7. There is a 1.5 second delay between power on and power output.
  8. There is a 1.5 second delay between power on to each switched group.
