Notes

1. The minimum operating system is Solaris 2.3 (SunOS 5.3).
2. Solaris 2.3 requires patches 101318-12 and 101406-01.
3. Set the SS10 clock speed to 80MHz.
4. The SM52 covers SBus slots 0 and 1.
5. Mixing different module types is not supported.
6. Surface mounted Fuses F1301 and F1401 are not field replaceable.

Reference

SPARCstation 10 Model 514 Upgrade, 801-6065.

Notes

1. The minimum operating system is Solaris 2.3 (SunOS 5.3).
2. Solaris 2.3 requires patches 101318-12 and 101406-01.
3. Set the SS10 clock speed to 80MHz.
4. Do NOT use 501-2609-01 in the SS20.
5. The SM52 covers SBus slots 0 and 1.
6. Mixing different module types is not supported.
7. Surface mounted Fuses F1301 and F1401 are not field replaceable

Reference

SPARCstation 10 Model 514 Upgrade, 801-6065.

Notes

1. The minimum operating system is Solaris 2.3 (SunOS 5.3).
2. Solaris 2.3 requires patches 101318-12 and 101406-01.
3. Set the SS10 clock speed to 80MHz.
4. Do NOT use 501-2609-01 in the SS20.
5. The SM52 covers SBus slots 0 and 1.
6. Mixing different module types is not supported.
7. Surface mounted Fuses F1301 and F1401 are not field replaceable.

Reference

SPARCstation 10 Model 514 Upgrade, 801-6065.
