| LED Name |
LED color |
Description |
| Locator LED and button |
| White |
Enables you to identify a particular server. The LED is controlled using one of the following methods:
Issuing the setlocator on or off command
Pressing the button to toggle the indicator on or off.
This LED provides the following indications:
Off - Normal operating state.
Fast Blink - The server received a signal as a result of one of the preceding methods and is indicating
here I am - and that it is operational.
|
| Service Required LED |
Amber |
If on, indicates that service is required. The ALOM showdefaults command will indicate
any faults causing this indicator to light.
|
| Power OK LED and Power On/Off button |
Off |
The system is unavailable. Either it has no power or ALOM is not running. |
| Green |
Normal Operating State |
| Green - Standby Blink |
Indicates the system is running at a minimum level in standby mode and ready to be returned to its normal operating state. The service processor is running |
| Green - Slow Blink |
Indicates that a normal transitory activity is taking place. This could indicate that the system diagnostics are running, or that the system is booting. |
| Power on/off Button |
Turns the system on and off. This button is recessed to prevent accidental server power-off.
There is no Power On/Off button on the rear panel. |
