IBM DFHS-32160-S2S (2.1GB)

3 1/2" 7200 RPM Single Ended Fast/Wide SCSI

Workstations: Ultra 1E, 2
Ultra 450
Servers: Enterprise 450
Enterprise 150, 3000

Options 765 / 766 / 768 / 769 / 770 / 775 / 790 / 791 / 792
5151 / 5152 / 5153 / 5161 / 5511 / 5512 / 5513

370-1956 540-2706 540-2730
1" Height
Starfire
SSA FRU
8.4GB Disk Card FRU
w Bracket 540-2413 or 540-2764
Axx/E150/E3000 FRU
w R Bracket 330-1951
w L Bracket 330-1952

Power

0.96 Amps @ +5Vdc
0.36 Amps @ +12Vdc
9.1 Watts Reading/Writing

Notes

  1. The minimum operating system is Solaris 1.1.
  2. This drive was disqualified. Approximately 200 were shipped.

Reference

2.1 Gbyte 7200 RPM Disk Drive Specifications, 802-4058.
