Fujitsu MAW3073NC (73.4GB)

3 1/2" 10000 RPM Low Voltage Differential Ultra-320 SCSI

Workstations: Sun Blade 2500
Servers: Sun Fire V60x, V65x, V20z, V40z
Sun Fire V120, V125, V210, V240, V250, V440
Sun Fire V1280, E2900
Disk Arrays: StorEdge A1000, D1000
StorEdge S1, D2, 3120, 3310, 3320, D240
Telco: Netra 120, 1280, CT 410/810

Options 5127 / 5245 / 5263 / 5264 / 5265 / 5886 / 7205 / 9256
Options XRA-SC1CA-73G10K / XRA-SC1CB-73G10K
Options XTA-SC1NC-73G10K / XTA-3310-73GB-10K
390-0252
1" Height
Allegro 9LE+
CA06550-B12000
371-0292 371-1453 540-5455 540-5456
V20z/V40z FRU
1" Bracket / 73.5GB
9256A		 V20z/V40z FRU
1" Bracket / 73.5GB
9256A-Z
 Spud Bracket FRU
1" Bracket 540-3024
Plate 340-5928
Plate 340-7269		 Spud Bracket FRU
1" Bracket 540-3024
540-5563 540-5771 540-5937 540-6056
3000 Series FRU
1" Bracket
XTA-3310-73GB-10K		 CT 410/810 FRU
N120/N1280/V120 FRU
NEBS Level 3
1" Bracket 540-3024
Plate 340-5928
Plate 340-7269		 V60x/V65x FRU
1" Bracket 330-3696
-04 = 390-0252		 3000 Series FRU
1" Bracket
XTA-SC1NC-73G10K
02/06/04 - 10/26/05
540-6289 540-6448 540-6599
Spud Bracket FRU
1" Bracket 540-3024
XRA-SC1CA-73G10K		 3000 Series FRU
1" Bracket

XTA-SC1NC-73G10K
(From 10/26/05)
XTA-3310-73GB-10K		 Spud Bracket FRU
1" Bracket 540-3024
540-6600 540-6603 540-6936
Spud Bracket FRU
1" Bracket 540-3024
Plate 341-1986
 NEBS Level 3
1" Bracket 540-3024
Plate 341-1986
 3000 Series FRU
1" Bracket
Lucent Technologies
540-5652
StorEdge D240
Left/Right FRU
Assy 599-2652
or Assy 540-5703
Drive 540-5456
Bracket 340-6476

Notes

  1. Drive 390-0252 was released in December 2005. (WO_32215)
  2. Use of 390-0252 in 540-6448 was waivered in October 2005. (WO_31708)
  3. XTA-SC1NC-73G10K changed from 540-6056 to 540-6448 in October 2005. (WO_31505)
  4. Drive 390-0252 was added to 540-5455, 540-5456, 540-5563, 540-5771, 540-5973, 540-6056, 540-6289, 540-6599, 540-6600, and 540-6603 in December 2005. (WO_32215)
  5. Option 5264 changed from 540-5456 to 540-6599 in January 2006. (WO_32023)
  6. Option 5265 changed from 540-5771 to 540-6603 in January 2006. (WO_32023)
  7. XRA-SC1CB-73G10K changed from 540-5455 to 540-6600 in January 2006. (WO_32023)
  8. XTA-3310-73GB-10K changed from 540-5563 to 540-6448 in October 2006. (WO_34374)
