Fujitsu MAJ3364MC (36.4GB)

3 1/2" 10000 RPM Single Ended Ultra-1 SCSI

Workstations: Ultra 60, 80
Servers: Enterprise 250, 450, 220R, 420R
Sun Fire V120
Telco: Netra t1, T1, 120
Netra t1120/1125, t1400/1405
Netra ct 400/800, CT 410/810, ft 1800
Netra st A1000, st D1000, st D130
Disk Arrays: StorEdge A1000, D1000
StorEdge UniPack, MultiPack
StorEdge D240

Options 5242 / 5243 / 5244 / 5249 / 5257 / 5884

390-0051 390-0059
1" Height
Allegro 6
1" Height
Allegro 6
UniPack Drive
540-4521 540-4689
Spud Bracket FRU
w Drive 390-0051
w 1" Bracket 540-3024
Netra ct/st/CT/T1/120 FRU
NEBS Level 3
w 1" Bracket 540-3024
w Plate 340-4288 or 340-6640
or Plate 340-5928 or 340-7269
540-4919 540-5693
Netra t1/t1400/1405 NEBS FRU
w Drive 390-0051
w 1" Bracket 540-3024
Netra t1400/1405 FRU
NEBS Level 3
w Drive 390-0051
w 1" Bracket 540-3024
540-4520 595-6394
StorEdge D240
Center FRU
12-Slot A1000/D1000 FRU
w 1" Bracket 540-3024
w Plate 340-4288 or 340-6640
or Plate 340-5928 or 340-7269
StorEdge D240
Left/Right FRU
Assembly 599-2593
or Assembly 540-5702
Drive 540-4521
w Bracket 340-6476

Notes

  1. The LVD capability of this drive is not qualified by Sun.
  2. The 160Mbyte/sec capability of this drive is not qualified by Sun.
  3. Drives 390-0051 and 390-0059 are the same Fujitsu model number.
  4. Drives 390-0051 and 390-0059 respond to a SCSI Inquiry command with different values.

Reference

36 Gbyte 10000 rpm Disk Drive Specifications, 806-4798.
