Fujitsu MAB3091SC (9.1GB)

3 1/2" 7200 RPM Single Ended Ultra-1 SCSI

Workstations: Ultra 2
Ultra 30, 60, 450
Servers: Enterprise 250, 450
Enterprise 3000
Telco: Netra t1120/1125, ft 1800
Netra t1
Disk Arrays: StorEdge A1000, D1000, A7000
StorEdge UniPack, MultiPack

Options 5163 / 5229 / 5230 / 6288 / 6956

370-3413
1" Height Allegro 4L
540-2942 540-3704 540-3720 540-4004
RSM FRU
w Bracket 370-2304
Spud Bracket FRU
w 1" Bracket 540-3024
12-Slot A1000/D1000 FRU
w 1" Bracket 540-3024
w Plate 340-4288 or 340-6640
or Plate 340-5928 or 340-7269
Netra ft 1800 FRU

Notes

  1. The 9.1GB Drive is not compatible with A7000 Option 9652, Chassis 540-3666.
  2. The 9.1GB Drive requires A7000 Option 9656, Chassis 540-3841.

Reference

9 Gbyte Disk Drive Specification, 805-3935.
