Delta A247
760 Watt Power Supply

300-2233
Type A247
AC Input Power Supply
Specification 950-5843
UL 60950-1 2nd Edition
EN 60950-1 2nd Edition


AC Input

90-264Vac 47-63Hz 9.0A RMS Max

DC Output

+12V +3.35Vsb
62.3A 3.6A

Efficiency of 300-2233

100V 20% Load ≥83%
50%-100% Load ≥87%
230V 10% Load ≥83%
20% Load 90%
50% Load 92%
100% Load 90%

Notes

  1. Power Supply Efficiency affects the current draw in AC
    Watts from the branch circuit. As efficiency increases,
    the current draw in AC Watts decreases.
  2. To calculate maximum theoretical current draw in AC Watts,
    multiply the maximum power supply output in DC Watts by
    the reciprocal of the power supply efficiency.
  3. Theoretical values are typically higher than published values
    which are based on measured outputs under controlled test
    conditions.
