Delta D0115284
(or AcBel API4FS35-470G)
1000 Watt Power Supply

Workstations: Ultra 25, 40, 40 M2, 45

300-1800
AC Input Power Supply
Mitac 471045200105 (Delta)
Mitac 471045900022 (AcBel)
AVL Datasheet 300-1800

AC Input

100V 50-60Hz 13.0A
110-127V 50-60Hz 12.0A
200-240V 50-60Hz 7.0A

DC Output

+3.3V +5V +12Va +12Vb +12Vc +12Vd +5Vsb -12V
30A 33A 17A 17A 17A 17A 3.0A 0.5A
Maximum combined output of +3.3 and +5 is 240 Watts
Maximum combined output of +12 is 768 Watts
Efficiency is 67% with 10% load
Efficiency is 76% with 55% load
Efficiency is 72% with 100% load

Ultra 25 Codename: South Side
Ultra 40 Codename: Sirius
Ultra 40 M2 Codename: Stuttgart
Ultra 45 Codename: Chicago
