Astec AA22780
400 Watt Power Supply

Telco: Netra 240, 440

300-1567 300-1845
Type D158
DC Input Power Supply
System Specification 950-4001
Type D158
DC Input Power Supply
System Specification 950-4001
L

DC Input

-48Vdc to -60Vdc 12A

DC Output

+3.3V +5V +12V -12V +5VSB
20.3A 17.2A 25.0A 0.42A 2.8A

Netra 240 Codename: Enchilada 19
Netra 440 Codename: Chalupa 19

Notes

  1. The +12V output is labeled 23.0A on the Power Supply.
  2. The +12V output is rated 25.0A in Sun Specification 950-4001-01.
  3. The combined output of +3.3, +5, and +12 can not exceed 381 Watts.
