Artesyn A211
4000/5100 Watt Power Supply

Servers: Sun Fire 12K, 15K, E20K, E25K

Option C-HE-PWR2-KIT-Z

300-1813
Type A211
AC Input Power Supply
Specification 950-4818
July 2006
L

AC Input

200-240 Vac 47-63Hz 24 Amps RMS Maximum per line cord with 78.5A load current
200-240 Vac 47-63Hz 31.3 Amps RMS Maximum combined with 104A load current
17 Amps RMS Maximum per line cord

DC Output

+49.87V 80A 3990 Watt with one AC input source
+49.87V 104A 5093 Watt with two AC input sources

Notes

  1. This Power Supply weighs 19.5 Kilograms (43 Lbs).
  2. Front Power Supplies are labeled PS0, PS1, and PS2 from right to left.
  3. Rear Power Supplies are labeled PS3, PS4, and PS5 from right to left.
  4. There is a different part number for the upper and lower power cord.
  5. 1.95GHz Uniboards in the 12K/15K/E20K/E25K require power supply 300-1813.
  6. The 300-1813 is installed in the E20K-BASE-3-Z and E25K-BASE-3-Z chassis.
  7. 2GB DIMMs in the E25K require power supply 300-1705, 300-1917, or 300-1813.
  8. Power Supply 300-1813 and Chassis 371-2540 are 1.95GHz USIV+ requirements.
    Option C-HE-PWR2-KIT-Z includes six 300-1813 Power Supplies and two 371-2540 Power Chassis.
  9. Power Chassis 371-2540 includes Keying Bracket 341-3304.
    Keying Bracket 341-3304 prevents mixing Types A141 and A196 with Type A211.
