AcBel API4FS35-471G
1000 Watt Power Supply

Workstations: Ultra 40 M2

300-2127
AC Input Power Supply
AVL Datasheet 300-2127

AC Input

100V 50-60Hz 13.0A
110-127V 50-60Hz 12.0A
200-240V 50-60Hz 7.0A

DC Output

+3.3V +5V +12Va +12Vb +12Vc +12Vd +5Vsb -12V
30A 33A 17A 17A 17A 17A 3.0A 0.5A
Maximum combined output of +3.3 and +5 is 240 Watts
Maximum combined output of +12 is 768 Watts
Efficiency is 67% at 100V AC Input
Efficiency is 80% with 20%, 50%, and 100% load at 115V AC Input
Efficiency is 80% with 20%, 50%, and 100% load at 230V AC Input

Ultra 40 M2 Codename: Stuttgart
